Van Damme Digitour AES/EBU & DMX 32 pair multicore

Name: Van Damme Digitour AES/EBU & DMX 32 pair multicore
Brand: Van Damme
SKU: 268-482-032
Price: 652.50 GBP
Availability: InStock

268-482-032

RATING

QUANTITY

Stock count: 630

PRICE (EX. VAT)

£652.50

268-482-032

RETAIL PRICES (EX. VAT)

10m+

£65.25

100m+

£54.38

17%

Product Information

Low capacitance and stable characteristic impedance ensure that signals remain error and jitter free over long distances and make these cables ideal for DMX512 as well as AES/EBU and analogue audio signals. The unobtrusive black jacket make them more suitable than the existing Green Series for the lighting and presentation markets. Suitable for any 100 to 110 Ohm balanced data application such as RS422, RS485, and timecode.

Individual Pairs:
Conductor	7 x 0.16 mm bare ultra-pure oxygen-free copper
Conductor size	7 x 0.16 mm, 0.14 mm², AWG 26/7
Insulation	Foam skin polyethylene, 1.10 ± 0.10 mm
Colour Code	White/Blue
Drain wire	7 x 0.16 mm tinned ultra-pure oxygen-free copper
Drain wire size	7 x 0.16 mm, 0.14 mm², AWG 26/7
Screen	24 µm Aluminium/Polyester Foil > 150% coverage
Jacket material	Flexible PVC composite, Pebble Grey, RAL 7032
Overall diameter	2.90 ± 0.15 mm
Overall Construction:
Jacket material	Flexible PVC composite, Jet Black, RAL 9005
Overall diameter	23.40 ± 0.15 mm
Bend radius	15 x overall diameter
Operating temperature	-15 to +70 ⁰C

Resistance	Conductor	< 144 Ohm/km
	Insulation	> 5000 MOhm/km
Capacitance	Core to core	50 pF/m
	Core to screen	100 pF/m
Impedance	1 - 4 MHz	110 ± 20% Ohms
Attenuation	3 MHz	7.05 dB/100 m
